Dura Composites Micro Mesh GRP grating features an anti-slip surface with a new finer grit which is ideal for water sports facilities and other recreational areas. The 10.5mm x 10.5mm open mesh prevents virtually all objects from falling through and is suitable for a wide range of footwear and sporting equipment.
The fine grit is also ideal for use in work areas such as refuelling pontoons as it is less abrasive on trailing equipment such as hoses.
d2 Dura Grating Micro Mesh is available in Dark Grey and Teak as standard, with other colours available as special order. Minimum order quantities apply. If your project requires access ramps, 23mm Micro Mesh can be easily combined with other heavy grit products in the range.
Technical information for our Standard Mesh Grating
Depth (mm)
Open Hole Size(mm)/Open Area
Weight (kg/m2)
Max Span 1.5kn Point Load @ 1% deflection
23mm
10.5 / 60%
11.5
600mm
Buying from Dura
Product Specifications
SKU
DG02325
Weight
60.61kg
Length
4070mm
Width
1300mm
Height
23mm
Grating Depth
23mm
Grating Colour
Teak
Grating Panel Size
4076 x 1300
SKU
DG02324
Weight
36.22kg
Length
3040mm
Width
1040mm
Height
23mm
Grating Depth
23mm
Grating Colour
Teak
Grating Panel Size
3042 x 1041
SKU
DG02326
Weight
72.73kg
Length
4076mm
Width
1560mm
Height
23mm
Grating Depth
23mm
Grating Colour
Teak
Grating Panel Size
4076 x 1560
SKU
DG02321
Length
3038mm
Width
1038mm
Height
23mm
Grating Depth
23mm
Grating Colour
Dark Grey
Grating Panel Size
3042 x 1041
SKU
DG02322
Length
4070mm
Width
1296mm
Height
23mm
Grating Depth
23mm
Grating Colour
Dark Grey
Grating Panel Size
4076 x 1300
SKU
DG02323
Length
4070mm
Width
1554mm
Height
23mm
Grating Depth
23mm
Grating Colour
Dark Grey
Grating Panel Size
4076 x 1560
Delivery
Standard lead time on orders is 3 – 5 working days (Mainland UK; stock dependent).
Large orders may be subject to palletized deliveries which are to the property kerbside only. Your order will need to be unloaded by hand (hand-balled) off the lorry side. A person must be present to help unload the goods and sign for receipt. Delivery drivers are not insured to help unload the goods beyond the property kerbside.
If your postcode prefix is listed below we would be happy to provide a delivery quote. Please call our Websales Customer Care Team on 01255 446838 to place your order.
Northern Ireland (All BT postcodes)
Scottish Highlands (AB30, AB33 – AB38, AB41 – AB56, FK17 – FK21, IV1 – IV63, PA20 – PA80, PH15 – PH27, PH30 – PH45, PH49, PH50, KW1 – KW18)
Scottish Offshore (HS1 – HS9, KA27, KA28, ZE1 – ZE3)
Scottish Borders (All TD and DG postcodes)
Isle of Man (All IM postcodes)
Isle of Wight (PO30 to PO41)
Isles of Scilly (TR21 to TR25)
Channel Islands incl. Jersey, Guernsey, Alderney, Sark & Herm (All JE and GY postcodes)
Returns & Exchanges
If you wish to return or exchange your goods, please complete the form dispatched with your order and return within 14 days to the address below. Items must be unused and in perfect, resale condition and in their original packaging, and the Returns Form must be included. Once the goods have been received and inspected to check they meet the requirements outlined above you will receive a refund (credited back to the method you paid with) or a new shipping notification for your requested exchange within 7 working days of receipt.
The replacement item(s) will be shipped to you free of charge (once per customer). Please note we cannot exchange items of differing value. If you choose to return any items that were purchased as part of a promotion, and by returning part of your order your remaining total means you are no longer eligible for the original discount, the value of that discount will be deducted from any refunds due.
Please note the customer is responsible for the postage to return the item to us. We recommend using a Signed For recorded postal service as Dura Composites Ltd are not liable for any items that go missing en-route back to us. Thank you for your cooperation.
Returns should be sent to:
Dura Composites Returns Dept.
Dura Operations Centre,
Telford Road,
Clacton on Sea,
Essex CO15 4LP
If you have not yet been issued with your Unique Returns Number (URN) or require a Returns Form, please e-mail customercare@duracomposites.com or call us on +44 (0)1255 423601 to discuss your request.
Warranty
All of our products come with a reassuringly long warranty to give you that piece of mind. For details of terms and conditions and how to activate your warranty, click below.
At Dura we are one of the world’s leading suppliers of composite materials and that is in no small part due to the incredible services we provide.
Apart from our personalised advice from an in-depth 25 year multi-industry experience, we also offer specialised cutting/fabrication and installation services to tailor to your individual needs.
Our market leading CAD and structural engineer teams are also available for stand-alone design and part of a larger integrated design scheme to give you that unique service that guarantees your project will run smoothly.
Choosing the compatible Fixing for your Dura Micro Mesh Grating
We have exclusively designed a fixing to work seamlessly with the 23mm Micro Mesh. Our Micro Dome comes in a clever Dark Grey colour that blends into the dark grey grating seamlessly for that smooth finish if you’re looking to hide the fixings.
Micro Dome Washer
Small Dome Washer
Large Dome Washer
Extra Large Dome Washer
Uni-Strut Clamp
Channel Clamp
Micro Mesh 23mm
– Recommended Fixing for Product – Compatible, for use only with the recommendation from your Dura Representative – Not Compatible or Recommended
